Plugboard, Universal

The Universal Plugboard is a universal connection board designed for use in MG series kits, such as the M249, as well as other compatible systems including the Fusion Engine. It is suitable both as a replacement part and for custom wiring setups when a model-specific switchboard is not available.

The board features one 5-pin header for the main wiring harness and four 2-pin headers labeled CON1 through CON4. This provides a practical and organized solution for connecting key parts of the system.

The individual headers are assigned as follows:

• CON1 = Nozzle Solenoid
• CON2 = Poppet Solenoid
• CON3 = Selector Input
• CON4 = Trigger Input

This plugboard is a useful choice for users handling service, repairs, or custom wiring on compatible HPA systems and looking for a universal and clearly arranged wiring solution.

Key features:

• Universal plugboard for compatible systems
• Used in MG series kits such as M249
• Also compatible with Fusion Engine systems
• Suitable for custom wiring
• 1× 5-pin header for the main wiring harness
• 4× 2-pin headers CON1–CON4
• Clearly assigned header functions
